Murata Power Solutions Digital panel meter Murata Power Solutions LED 4-digit 36.22 × 22.1mm ACM20 series

Specification
Cutout height: 22.1 mm *Cutout width: 36.22 mm *Display type: LED *Number of display digits: 4 *Number of phases: 1 *Depth: 23.11 mm *Character height dimension: 9.14 mm *Meter accuracy : ±1% * Minimum temperature: 0°C * Maximum temperature: +60 * Series: ACM20 * ACM20-Four-Function AC power meter. ACM20 series AC power meter is the most important measurement value, that is, voltage of equipment equipped with power supply. , Current, active power (watts), power factor. The front panel selector switch has two modes: fixed reading for any of the four parameters and continuous reading for cycling through all four. The miniature size is ideal for UPS power supplies, power strips, laboratory equipment, alternative energies, and other products that require precise monitoring of AC power. .4 Function AC Power Meter Large 9.2 mm bright red LED display AC voltage, current, watts, power factor (or Hertz) display mode: continuous automatic circulation and fixed 2 kinds of complex voltage and current waveform True -RMS reading Different versions available:-10 A, power factor reading, part number; 823-3595 823-3595-32 A, power factor reading, part number 823-3586 823-3586-100 A, power factor reading, part number 823-3592 823-3592-10 A, power factor reading, part number 823-3598 823-3598-32 A, power factor reading, part number 823-3589 823-3589-100 A, power factor reading, part number 823 -3602 823-3602 Built-in current transformer for easy installation Universal, 85-264 V ac (47-63 Hz) operating range Integrated polycarbonate housing fits 0U and 1U racks Surface mount design occupies panel surface Is minimal
