IMAO NDXN index plunger (nose lock type)
#Grup produk P115805956
Spesifikasi
| Heat Resistance Temperature (°C) | 150 |
|---|---|
| Material (Main Unit) | SUS303 |
| Material (coil Spring) | SUS302WPA |
| Material (knob) | SUS303, electrolytic polishing |
| ROHS Directive (Corresponding to 10 Substances) | Correspondence |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Informasi Produk
Description
A hand-operated spring plunger that retracts the nose by pulling the knob and can be easily dispositioned, and the nose returns to its original state by the built-in spring when the hand is released.
The nose lock type can be locked (fixed) with the nose retracted by rotating 90 ° with the knob pulled.
When using the index plunger by completely screwing it into the plate, chamfer the tap hole on the plate side.
It is a RoHS directive compliant product.
The nose lock type can be locked (fixed) with the nose retracted by rotating 90 ° with the knob pulled.
When using the index plunger by completely screwing it into the plate, chamfer the tap hole on the plate side.
It is a RoHS directive compliant product.
