IMAO APS Top Mount Module APS-E APS140-E

This product is spring clamp specification. Applying air pressure to the unclamping port will unclamp, and releasing the air pressure will clamp with the spring. After spring clamping, applying air pressure to the boost port will increase the clamping force. Can be used with threaded or gasket piping. Ideal for mounting to fixture plates and MC plates. When spring clamping, the boost piping port becomes a breathing hole, so do not block it. Install a filter if necessary. [Features of IMAO APS (IMAO Automatic Positioning System)] Quick replacement Reduces setup time by 90% Positioning and fixing can be done simultaneously Clamps with spring, unclamps with air (air source can be disconnected when clamping) High repeat positioning accuracy Repeat positioning accuracy 5μm or less Positioning with tapered pin Low cost Total cost reduction System uses factory air, initial cost reduction Excellent maintainability
