Siglent Current Shunt
#Grup produk P115731998
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
The Siglent SCD30A is a precision current shunt designed for accurate current-to-voltage conversion in laboratory and research applications. It enables direct measurement of current up to 30 A by providing a proportional voltage output of 10 mV/A, facilitating straightforward monitoring using standard measurement instruments such as oscilloscopes, data acquisition systems, or digital multimeters.
Feature
Technical Characteristics:Rated Current: Continuous measurement capability up to 30 A, suitable for DC and low-frequency AC applications.
Output Sensitivity: The shunt provides a linear output of 10 mV per ampere, simplifying the calculation of measured current values.
Low Resistance: Utilizes a precision low-resistance element to minimize power dissipation and voltage drop, reducing impact on the measured circuit.
Connector Configuration: Features robust terminal connections to ensure stable and repeatable measurements under varying test conditions.
Typical Applications:
Power electronics testing, including converters and inverters.
Battery discharge profiling and energy storage system evaluation.
General laboratory measurements where high-current signals must be observed with high fidelity.
The SCD30A Current Shunt offers a stable and reproducible method for current measurement, making it suitable for educational, research, and development environments where reliable data acquisition is essential.
