Fuji Electric Φ16 push button switch AH164 / AH165 Round large type
#Grup produk P115644717
Spesifikasi
| Button Color | Red |
|---|---|
| Button Shape | Mushroom (large) |
| Button Size (mm) | DIA23.5 |
| Contact Configuration | 1a1b |
| Electrical Durability | 100,000 times (AC220V 0.7A) |
| Insulation Resistance (MΩ) | over 100 |
| Mechanical Durability | 1,000,000 times or more |
| Operating Frequency (operation/hour) | 1200 (40% usage rate) |
| Product Name | Push-button switch |
| Protection Class | (Operation unit) IP40, closed type |
| Rated Insulation Voltage (V) | AC/DC250 |
| Relative Humidity | 45 to 85% RH (at -5 to 40°C) (no freezing or condensation) |
| Shock Resistance (m/s²) | Malfunction: 100, Durability: 500 |
| Terminal Shape | Solder terminal / tab terminal |
| Type | Non-illuminated type |
| Type of Operation | Momentary |
| Vibration Resistance | Resonance test: Double amplitude 0.1mm 10-55Hz, constant vibration endurance test: Double amplitude 3mm 16.7Hz |
| Withstand Voltage (V/minute) | Between live part and ground: AC2000, between opposite pole live part: AC1500 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Feature
SpecificationClosed end type
