RS PRO RS PRO XLR connector

Specification
Number of contacts: 4, Male/Female: Female, Mounting type: Cable mount, Body orientation: Straight, Color: Black, Contact plating: Silver, Housing material: Zinc, Terminal method: Solder, Rated current: 10A, Rated voltage: 250 V ac, contact material: brass, operating temperature Min: -30°C, operating temperature Max: +80°C, do not use as main connector. RS Pro cable mounting connector (with backshell). RS Pro multi-pole audio/video The connector is manufactured for professional use. "AXR"/"XLR" compatible connectors are precision manufactured with zinc die cast bodies and silver plated solid brass turning contacts. A big advantage of these connectors is the "squeeze" release clip, which allows quick removal of plugs and sockets with a simple push-down mechanism. Easy to wire and assemble, the collet placement accommodates cable diameters from 2.8 mm to 8.0 mm for effective cable grip. Every model boasts high reliability and excellent quality. Features and benefits. Solder tag with holes for improved retention of connections and high reliability. Black or natural shell color. Male or female types available.
