RS PRO RS Pro relay, 1c contact, 5V dc, 167 Ω
#Grup produk P115405394
Spesifikasi
| Contact Configuration | 1c |
|---|---|
| ROHS Directive (Corresponding to 10 Substances) | Correspondence |
| Rated Voltage (V) | DC5 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Feature
SpecificationCoil Voltage = 5V dc Contact Configuration = SPDT Switching Current = 2 A Terminal Type = Through Hole Coil Resistance = 167 Ω Maximum Switching Voltage AC = 125V ac Maximum Switching Voltage DC = 60V dc Application Type = Signal Length = 12.5mm Depth = 7.5 mm Height = 10mm Dimensions = 12.5 x 7.5 x 10mm Operating temperature Min = -30°C UL (file number E133481), CQC (file number CQC02001001948). Subminiature signal relay. High coil sensitivity: 150 mW 2 A switching capability ( max) Contact Rating: 0.5 A (125 Vac), 1 A (30 Vdc) Washable
