RS PRO RS PRO Push Button Switch, Latch, PCB, DPDT

Operating Characteristics = Latch Illumination = None Mounting Type = PCB
Push Button Color = Black Contact Configuration = DPDT
Rated voltage = 28V dc
IP protection rating = IP67
Contact current rating = 3 A @ 250 V ac
Contact Material = Silver Contact DC Voltage Rating = 28V

UL, CSA. Fully sealed IP67 12mm pushbutton switch. This fully sealed switch features a double shell case that provides enhanced mechanical strength and high electrical insulation.
This switch has two "O" ring front seals that maintain a seal during operation.
The back of the switch is also fully sealed to protect it from running water.
The contacts are ideal for both low level switching (10 mA 50 mV → 10 μA, down to 5 V dc) and power applications (3 A @ 250 V ac).
