RS PRO RS PRO IDC connector

Specification
Number of contacts: 26 * Male/Female: Female * Pitch: 2.54mm * Mounting type: Cable mount * Body orientation: Straight * Terminal method: IDC * Rated current: 1A * Contact plating: Gold * Series: SC * Operating temperature Min: -45°C *Operating Temperature Max: +105°C *Contact Material: Copper Phosphate *UL Certified. RS 2.54mm Universal PCB Box Header and IDC Ribbon Cable Socket. 2.54mm pitch PCB compatible with BS9525-F0023 compliant connector Mounting box header and IDC ribbon cable socket. This 2.54 mm universal board header and IDC socket features a gray UL94V grade fiberglass filled polyester housing and gold flash plated contacts and terminals. The 2.54 mm universal header is fully covered with a long ejector latch. The 2.54 mm Universal IDC Ribbon Cable Socket has an open design with no center bump, making it ideal for daisy chain connections. The parts are equipped with strain reliefs for quick cable insertion.
