Compact, high quality and economical snap-in mounting: By using the accessory square mounter (AT-529), panel mounting with snap-in is possible. In addition, attaching a bezel helps improve the panel design.
UL 94V-0 case: The molding material of the case is UL 94V-0 certified product (self-extinguishing property), and resin with excellent arc resistance and insulation is used for long life and from low load to high load. , High performance effect is maintained.
Improved insulation: An insulating wall inside the case is provided to improve the insulation between each terminal and improve durability.
Shut out flux intrusion: The terminal part has an epoxy seal to prevent flux intrusion and terminal backlash, further improving contact stability.
Improved insulation between terminals: Multiple insulating walls are provided between terminals to prevent deterioration of insulation and withstand voltage performance.
Light operation feeling: A light touch operation feeling.
High torque bushing: The joint between the bushing and the case cover uses a high torque structure to increase strength.
Excellent corrosion resistance: Stainless steel is used for the case cover. In addition to improving corrosion resistance, we are improving safety in various environments and expanding its applications.
Large terminal hole (hole 1.1 x 2 mm): Considered for easy wiring work. Compatible with two AWG # 20 to # 24 single wires and stranded wires.
Communication equipment / wireless application equipment, electronic measuring instruments, automation equipment, office equipment, consumer electronic equipment, etc.
*<> of function operation is momentary *Operation part is sold separately.
NKK Switches (formerly Nippon Kaikei) Pushbutton Switches E Series
#Grup produk P115164114
Spesifikasi
| Button Color | Blue, black, green, red, white, yellow (sold separately) |
|---|---|
| Button Shape | Circle (sold separately) |
| Insulation Resistance (GΩ) | 1 or more (DC500V) |
| Operating Temperature Range (°C) | -10~70 |
| Optional Accessories | Round nut (AT-501), mounting ring (AT-507), operation button (AT-443, AT-442, AT-465)<br> Hexagon nut (AT-513), internal tooth washer (AT-509) |
| ROHS Directive (Corresponding to 10 Substances) | Correspondence |
| Standard | UL,C-UL |
| Type | Non-illuminated type |
| Withstand Voltage (V/minute) | AC1k or more (between terminals), AC1.5k or more (between terminals and earth) |
