NIDEK Components (formerly Nidec Copal Electronics/Fujisoku) Non-cleaning type ultra-small push switch
#Grup produk P115160738
Spesifikasi
| Button Color | White / Red / Black / Gray / Green / Blue / Orange / Yellow / Brown |
|---|---|
| Button Shape | Round |
| Contacts Spacing (mm) | 2.54 |
| Electrical life | 10000 times at maximum rating, 50000 times at 0.4 VA |
| Insulation Resistance (MΩ) | 10,000 or more (DC250V) |
| Number of Poles | Single pole |
| Operating Temperature Range (°C) | -20~+85 |
| Operation Mechanism | Standard |
| Rating | Maximum: AC / DC48V 50mA, Minimum: AC / DC20mV 1μA |
| Storage Temperature Range (°C) | -40~+85 |
| Switch | OFF-(ON) |
| Terminal Shape | PC terminal |
| Type | Non-illuminated type |
| Type of Operation | Momentary |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Since the contact part is gold-plated, it is ideal for use in the minute current region.
