High contact reliability. A twin contact clip mechanism is used for the contact part.
Can be washed as a whole. All types have a complete sealing mechanism.
Since the contact part is gold-plated, it is ideal for use in the minute current region.
NIDEK Components (formerly Nidec Copal Electronics/Fujisoku) Miniature push button switch
#Grup produk P115151873
Spesifikasi
| Button Shape | Round |
|---|---|
| Contacts Spacing (mm) | 2.54 |
| Electrical life | 10000 times at maximum rating, 50000 times at 0.4 VA |
| Insulation Resistance (MΩ) | (Initial) 500 or more (250V DC) |
| Number of Poles | Single pole |
| Operating Temperature Range (°C) | -20~+85 |
| Operation Mechanism | Standard |
| Rating | 0.4VA AC, DC Max: AC/DC48V 50mA, Min: AC/DC20mV 1μA |
| Standard | UL certified product |
| Storage Temperature Range (°C) | -40~+85 |
| Switch | ON-(ON) |
| Terminal Shape | PC terminal |
| Type | Non-illuminated type |
| Type of Operation | Momentary |
