Short body structure. The short body structure with a body length of 10 mm has realized space saving of equipment.
Bright and uniform illuminated surface. A high-brightness LED is used for the illuminated area to obtain a bright and uniform illuminated surface.
There are two mounting methods. Two types of mounting methods can be selected: printed circuit board mounting method and panel snap-in method.
Snap action mechanism on the switch. A light feeling can be obtained by adopting a snap action mechanism in the switch part.
UL. CSA certified product. All types are UL and CSA certified products. (However, the indicator light is excluded.)
* Switch guard is sold separately. Select the switch guard for LP2S.
NIDEK Components (formerly Nidec Copal Electronics/Fujisoku) Illuminated switch LP series
#Grup produk P115149294
Spesifikasi
| Bouncing | 10 ms or less |
|---|---|
| Button Color | White |
| Button Shape | Square |
| Contact | Gold plate |
| Electrical life | 50,000 times (AC / DC 48V 50mA), 200,000 times (AC / DC 0.4VA) |
| Flange | With flange |
| Insulation Resistance (MΩ) | 100 or more (DC500V) |
| Number of Poles | Single pole |
| Operating Temperature Range (°C) | -15~+60 |
| Plate | (Switch) 12 x 12 |
| ROHS Directive (Corresponding to 10 Substances) | Correspondence |
| Rating | (Maximum) AC / DC 0.4VA, Operating voltage range: 20mV to 48V, Operating current range: 0.1mA to 50mA, (Min) AC / DC 20mV 0.1mA |
| Storage Temperature Range (°C) | -25~+70 |
| Stroke (mm) | (Full stroke) 2.3, (Lock stroke) 1.5 |
| Terminal Shape | Solder terminal |
| Type | Illuminated |
| Type of Operation | Momentary |
