A surface mount terminal type that has been renewed from the conventional product (A6S) and has improved solder heat resistance. Mounting is compatible with the conventional product (A6S), and the same shape has improved solder heat resistance. (Peak soldering temperature: 260°C)
The contact area is gold plated and the twin contacts have a self-cleaning mechanism that slides to ensure high reliability.
A type with washable sealing tape is available.
OMRON Slide DIP switch A6S-H
#Grup produk P115120226
Spesifikasi
| AS ONE Part Number | 64-3336-59 |
|---|---|
| Color | (Strike) White |
| Contact Configuration | 1a (normally open contact) |
| Dimension A (mm) | 11.1 |
| Electrical Durability | 1000 times or more |
| Electrical Rating | 24 mA 25 mA, 3.5 V DC 10 μA (minimum current) |
| Insulation Resistance (MΩ) | 100 or more (at 250 VDC) |
| Mass (g) | 0.41 |
| Number of Poles | 4 |
| Operating Humidity Range | 35 to 95% RH (at +5 to + 35 ° C) |
| Operating Temperature Range (°C) | -20 to +70 60% RH or less (with no icing or condensation) |
| Shock Resistance Malfunction (m/s²) | 300 or more |
| Type | Flat type (standard) |
| Vibration Resistance (Malfunction) | 10-55Hz double amplitude 1.5mm |
| Withstand Voltage | Between terminals: AC500V 1min |
