Heat generation is reduced by the leaf spring mechanism unique to the rocker switch for power supply that emphasizes safety.
The unique forced separation mechanism realizes contact separation even in the event of an abnormality such as contact welding.
Prepare neon illumination that can directly apply the power supply voltage.
Contact gap 3 mm or more.
A wide variety of caps and flanges are available.
Obtained UL, CSA and VDE standards. EN standard compliant.
OMRON Rocker Switch A8A
#Grup produk P115118708
Spesifikasi
| AS ONE Part Number | 64-3338-74 |
|---|---|
| Allowable Operating Speed | 1~500mm/s |
| Allowable Operating Speed (m/s) | 0.001~0.5 |
| Allowable Operation Frequency (times/minute) | Mechanical: 30 or less, Electrical: 20 or less |
| Ambient Humidity (% RH) | 45-85 or less |
| Cap Color | Red |
| Color (Cap) | Red |
| Display | l,○ |
| Electric Shock Protection Class | Class II |
| Electrical Durability | 20,000 times or more |
| Inrush Current (A) | Up to 100 (100 ms or less) |
| Insulation Resistance (MΩ) | 100 or more (with DC500V insulation resistance meter) |
| Mass (g) | About 15 |
| Mechanical Durability | 40,000 times or more |
| Operating Ambient Humidity (%RH) | 45~85 |
| PTI (Proof Tracking Index) | 175 |
| Pollution Degree (Environment to Use) | 2 |
| Protection Class | IEC IP40 |
| Safety Standard | UL(UL508),CSA(CSA C22.2 No.55),VDE(EN61058-1) |
| Shock Resistance (m/s²) | 500 |
| Shock Resistance Malfunction (m/s²) | 300 (malfunction within 1ms) |
| Type | Rocker switch |
| Type of Illumination | Non-illuminated |
| Vibration Malfunction Frequency (Hz) | 10 to 55 Double amplitude 1.5mm (malfunction within 1ms) |
| Withstand Voltage (V/minute) | Between same-polarity terminals, between different-polarity terminals: AC2000 50/60Hz<br> Between live metal parts and earth: AC 4000 50/60Hz |
