TAIYO (formerly Kuroda Pneumatics) SH valve Spool poppet type (Type H) (3HP-10E)
#Grup produk P114768515
Sebelum PPN:
Rp4.099.900 - Rp9.699.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Connector Diameter | A / B port: G3 / 8 |
|---|---|
| Driving System | Pilot type normal open type |
| Effective Section Area (mm²) | 10 |
| Lubrication | Not required (refueling is also possible, additive-free turbine oil 1 type in the case of refueling ISO VG32 equivalent) |
| Manual Operation Type | Push type |
| Mounting Side | freedom |
| Number of Ports | 3 port |
| Operating Pressure Range (MPa) | 0.15~1.0 |
| Operating Temperature Range (°C) | +5 to +50 (ambient temperature and fluid temperature) |
| Response Time (s) | ON: 0.025 or less, OFF: 0.030 or less |
| Suitable fluid | Air |
| Type of Sign | Direct type |
| Type of Switching | Normally open |
| Withstand Pressure (MPa) | 1.6 |
