TBUS−1N is a modular furniture−mounted connection bus enclosure that easily installs into a table or podium top. Once assembled, TBUS−1N enables you to connect any equipment to the room’s presentation system via cable access or passive interfaces. When the cables are not in use, they can be stored inside the unit, covered by the lid and out of sight.
NOTE: The TBUS enclosure, power socket, power cord & inserts are purchased separately.
Kramer Table Mount Modular Multi
#Grup produk P113700921
Sebelum PPN:
Rp3.499.900 - Rp7.399.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Accessories | Six self–locking ties, metal template |
|---|---|
| Color | Black and silver sandblasted finish |
| Dimensions (cm) | 21.4 x 19.2 x 13.6 |
| Fuse Rating | T 6.3A 250V |
| Humidity (%) | 10% to 90%, RHL non–condensing |
| Operating Temperature (°C) | 0 to +40 |
| Operating Temperature (°F) | 32 to 104 |
| Options | Inner frames, passive wall plates and interfaces,power socket kits, power cord |
| Power Source - Dual Power Kit Assemblies | 100-240V AC 50/60Hz, 5A, (Universal, USA, Germany and EU, France) or 220V AC, 50/60Hz, 5A (Israel, South Africa) |
| Power Source - Single Socket | 100-240V AC 50/60Hz, 5A (Universal, USA, Germany and EU, Belgium and France,Italy, Australia) or 220V AC 50/60Hz, 5A (Israel, South Africa) |
| Storage Humidity Range (%RH) | 5 to 95 (Non-Condensing) |
| Storage Temperature (°C) | -40 to +70 |
| Storage Temperature (°F) | -40 to 158 |
| Weight (kg) | 2 (TBUS–1N), Accessories (table clamps, metal template and so on): 0.89 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Feature
Modular Design — Tailors to your requirements.Cover — Black sand–blast or silver sand–blast anodized aluminum lid with a special opening for cable pass–through. (Note, other customized colors can be ordered).
Height Adjustment — Use screw holes to set the inner frame (ordered separately) to the desired height.
Power Sockets — Single or dual power socket openings are suitable for any of the following power sockets: USA, UK, Switzerland, Germany (the Europlug), Belgium–France, Italy, Australia, Israel, Brazil, South Africa or “Universal” for use anywhere.
Cutout Dimensions — 195 +2mm x 173 +2mm (7.68 +0.08in x 6.82 +0.08in).
