Spotlight that illuminates the remote probe, which is easy to use even in narrow spaces. mA current generation and 24V loop power supply.
milliamp process clamp meter
FLUKE Milliamp Process Clamp Meter FLUKE-772
#Grup produk P113693746
Spesifikasi
| Accuracy | [Generated DC current basics] Test lead: 0.2% + 2, [DC voltage] ± (1% + 5 counts), [Resistance] ± (1% + 5 counts), [Voltage frequency] ± (0.5% + 5 counts) ), [Current frequency] ±(0.5%+5 counts) |
|---|---|
| Basic Accuracy | [DC current] Test lead: 0.2%+2, Clamp: 0.2%+5/1%+5 |
| DC Vurrent | Test lead: 24.00mA, clamp: ±20.99mA/±21.0mA to ±99.9mA |
| DC current (mA) | Test lead: 24.00 |
| Dimensions (mm) | 246.2x70x43.7 |
| Dust / Water Protection | IP40 |
| Function | (HART resistance)O |
| Included Accessories | Soft case 3351060 (handled by service center), test lead TL75 red and black, alligator clip AC175 red and black, mini hook test lead TL940 red and black, strap hanger 669967, 337574 (handled by service center) |
| Inrush Current | 100ms effective value and peak value |
| Logging | (Memory) 65000 readings, (Interval) 1 second, settings changed from FlukeConnect Mobile App |
| Range | (DC voltage) 500.0mV, 600.0V, 1500V, (DC voltage) 999.9A, (Current frequency) 5.0Hz to 500.0Hz |
| Voltage Frequency (Hz) | (Range) 5.0 to 500.0 |
| Warranty Period | 3 years (1 year for cable and clamp) |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Feature
=Specification&""&attvalue[24V loop power] O [Measuring part] Jaw [Measuring part conductor diameter] 34
