□One-pass filter function that removes high frequency noise Inrush current (100ms effective value) measurement using INRUSH mode AC+DC mode that allows measurement even when AC and DC are superimposed Fluke355 that can also measure voltage and resistance
2000 amp clamp meter
FLUKE Clamp meter AC200A True RMS value AC/DC FLUKE-355
#Grup produk P113686588
Spesifikasi
| AC Current | 40.00A/400.0A/1400A |
|---|---|
| AC Voltage | 4.000V/40.00V/400.0V/600V |
| Accuracy | [Relative humidity] 5% to 10%, 90% to 100% RH @23°C: ±5.0%RH, 10% to 90% RH @23°C: ±2.5%RH |
| Basic Accuracy | DC current: ±(1.5%+15 counts)@40A range, ±(1.5%+5 counts)@400A, 2000A range, AC voltage: ±(1%+10 counts)@4V range, ±(1%+5) Count)@Other ranges: 10HZ to 100HZ, ±(3%+10 counts)@4V range, ±(3%+5 counts)◎Other ranges: 100.1Hz to lkHz |
| Category | Measurement: CAT III 1000V, CAT IV 600V |
| DC Voltage | 4.000V/40.00V/400.0V/1000V |
| DC Vurrent | 40.00A/400.0A/2000A |
| Dimensions (mm) | 300x98x52 |
| Dust / Water Protection | IP42 |
| Included Accessories | Soft case, 6 AA batteries, TL224 test leads (355), TP38 test probe (355), AC 285 alligator clip (355) |
| Resistance | 400.0Ω/4.000kΩ/40.00kΩ/400.0kΩ |
| Response Time | Temperature accuracy: 500ms |
| Temperature Sensor | Temperature accuracy: NTC |
| Warranty Period | 3 years |
