You can power / reset the computer at your fingertips away from the computer.
Since a branch cable is used, the power / reset switch on the PC side can also be used.
It is also useful as a substitute in case the power / reset switch of the main unit fails.
You can extend the power LED from the motherboard, and the blue ring will glow blue when the power is turned on.
Extend two USB 2.0 ports from the motherboard to the front.
Convenient for using USB devices.
It can be fixed to the desk with double-sided tape on the bottom.
No driver required. It works with the OS standard driver.
* The performance of each port depends on the connection destination.
* For motherboards with different pin arrangements, please also use the pin arrangement conversion cables EX-001 / EX-002.
* If you do not use a branch cable, leave the cover attached at the time of shipment. Prevents short circuit due to contact with the energized part inside the case.
* Incorrect connection may damage the motherboard or connected peripheral devices.
* The product is a general-purpose product, and operation is not guaranteed in all combinations.
Ainex PC Power Switch Button
#Grup produk P113628265
Spesifikasi
| Applicable Standard | USB 2.0/1. |
|---|---|
| Cable | Dedicated cable using mini D-Sub 15-pin connector |
| Cable Length (cm) | Main unit cable: Approximately 120 (directly attached to the main unit), Bracket with internal connection cable: Approximately 30 |
| Conform to | High-Speed (480Mbps / theoretical value) |
| Connector Shape | Power switch: 2-pin connector female, 2-pin connector male, reset switch: 2-pin connector female, 2-pin connector male, power LED: loose 2-pin connector female, USB 2.0: 2 x 5-pin connector female |
| Included Accessories | Bracket with cable for internal connection |
| LED Color | Blue |
| Supply Current (mA) | (Max / each port) 500 |
| Switch | Power supply: Push switch (Non-lock type), Reset: Push switch (Non-lock type) |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Warning
* The performance of each port depends on the connection destination.* For motherboards with different pin arrangements, please also use the pin arrangement conversion cables EX-001 / EX-002.
* If you do not use a branch cable, leave the cover attached at the time of shipment. Prevents short circuit due to contact with the energized part inside the case.
* Incorrect connection may damage the motherboard or connected peripheral devices.
* The product is a general-purpose product, and operation is not guaranteed in all combinations.
Feature
You can power / reset the computer at your fingertips away from the computer.Since a branch cable is used, the power / reset switch on the PC side can also be used.
It is also useful as a substitute in case the power / reset switch of the main unit fails.
You can extend the power LED from the motherboard, and the blue ring will glow blue when the power is turned on.
Extend two USB 2.0 ports from the motherboard to the front.
Convenient for using USB devices.
It can be fixed to the desk with double-sided tape on the bottom.
No driver required. It works with the OS standard driver.
