The front protection structure has IP66.
A PC loader port is standard equipment on the bottom. The PC loader supports SDC15 / 25/26/35/36.
In addition to being able to easily set the controller, it has a full range of logging functions such as trends.
Equipped with an event control function inside. Five internal events can be assigned to each event contact.
Azbil (Yamatake) Chiyotsutsukei
#Grup produk P113369317
Spesifikasi
| Approvals | CE marking compliant product |
|---|---|
| Communication Protocol | RS-485 (3-wire) Number of connected units: Up to 31 |
| Communication Speed | Up to 38400bps |
| Connector | Dedicated cable up to 2m |
| Event Type | Number of output points 3-point output type Relay output 1a (SPST) Type 32 types including PV, DEV, loop diagnosis, timer, heater burnout |
| Mass (g) | Panel mounting type: 150 (including dedicated mounting equipment), DIN rail mounting type: 200 (including socket) |
| Output Format | Relay output: 1c (SPDT) AC250V 3A; Voltage pulse output: DC19V±15%, internal resistance: 82Ω, allowable current: maximum DC24mA; Current output: DC0 to 20mA, 4 to 20mA (can be changed by setting) |
| Power Consumption | AC power supply model: 12 VA or less, DC power supply model: 7 VA or less (24 VAC) 5 W or less (24 to 48 VDC) |
| Power Supply Voltage | AC power supply model: AC100-240V 50 / 60Hz, DC power supply model: AC24V 50 / 60Hz / DC24-48V |
| Structure | IP66 (front) |
| Type of control | ON / OFF control, time proportional PID, current proportional PID |
