We have a wide variety of modules, number of teeth, etc., and are inexpensive and highly applicable.
* The accuracy grade is "equivalent".
KHK (KHK Gears) SS Spur Gear Module 0.5
#Grup produk P113180437
Spesifikasi
| Accuracy class | JIS N8 class (JIS B 1702-1: 1998), former JIS class 4 (JIS B 1702: 1976) |
|---|---|
| Backlash (mm) | 0 to 0.10 |
| Gear Cutting Reference Plane | Hole |
| Gear Surface Treatment | Cutting |
| Material | S45C |
| Module | 0.5 |
| Pressure Angle (°) | 20 |
| Surface Treatment | Black dyed |
| Tolerance A | H7 |
| Tooth Surface Hardness | 194HB or less |
| Tooth Type | Normal teeth |
| Tooth Width E (mm) | 5 |
| Type | Spur gear |
