NTN Cylindrical Roller Bearing NU200 Type
#Grup produk P112945907
Kondisi Barang:
Authorized Partner
Spesifikasi
| Basic Dynamic Load Rating (kN) | 140 |
|---|---|
| Basic Static Load Rating (kN) | 137 |
| Dimension D1 (mm) | 89.5 |
| Dimension EW (mm) | 113.5 |
| Dimension Fw (mm) | 83.5 |
| Inner Diameter (mm) | 70 |
| Main dimensions r (minimum) (mm) | 1.5 |
| Mass (kg) | 1.3 |
| Mounting Dimensions (mm) | da: min 78/db: min 78/dc: max 82/dd: min 86/de: min 92/Da: max 117/Db: max 117/min 115/ras: max 1.5/r1as: max 1.5 |
| Nominal Size | NU214EA |
| Outer Diameter (mm) | 125 |
| ROHS Directive (Corresponding to 10 Substances) | Correspondence |
| Race ring Shape | Cylindrical roller bearing |
| Width (mm) | 24 |
