Fuji Electric Square command switch AG28 / DG28 indicator
#Grup produk P112577122
Spesifikasi
| Frame | Corner frame |
|---|---|
| Impact Resistance Durability (m/s²) | 500 |
| Insulation Resistance (MΩ) | Between live part and ground / between different polarity live parts: 100 or more (at 500 VDC megger) |
| Lamp Type | LED |
| Lamp Voltage (V) | AC/DC24 |
| Method | All voltage type |
| Mounting Dimensions (mm) | 27.5 |
| Operation Mechanism | Flat ( 24) |
| Pollution Degree (Environment to Use) | 3 |
| Protection Class | Operation unit: IP65F (oil-proof type) |
| Rated Insulation Voltage (V) | AC/DC600 |
| Relative Humidity (%RH) | Inside the panel: 45-85 (at -5 to + 40 ° C) (however, no freezing or condensation) |
| Storage Temperature (°C) | -40 to +80 |
| Terminal screw | M3.5 + with square washer-Dual-use screw (self-up type) |
| Vibration Resistance | Resonance test: Double amplitude 0.1mm Frequency 10-55Hz / Constant vibration endurance test: Double amplitude 3.0mm Frequency 16.7Hz |
| Withstand Voltage | Between live part and ground / between different polarity live parts: 2500 VAC for 1 minute |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
