Fuji Electric Small magnetic proximity switch
#Grup produk P112577089
Spesifikasi
| Differential Distance | 1-12mm (vertical movement) |
|---|---|
| Insulation Resistance (MΩ) | 100 or more (at 500 VDC megger) |
| Mechanical life | 10 million times or more |
| Number of Contacts | 1NO (Normally open) |
| Operating Distance (mm) | (Vertical operating distance) 14 to 20 |
| Operating Time | 0.8 ms or less |
| Protection Class | IP40 (IEC standard) |
| Rated operating current (A) | 0.5 |
| Rated operating voltage (V) | AC/DC220 |
| Return Time | 0.05ms or less |
| Shock Resistance (m/s²) | 300 |
| Type | Small switch |
| Vibration Resistance | Double amplitude 1.5mm 10-55Hz (2 hours each in 3 directions of X, Y, Z) |
| Withstand Voltage | (Between terminal and ground) AC1500V 1 minute (when attached to insulation) |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
A magnetic proximity switch with the same dimensions as the micro switch (JIS C 4505).
