Cosel TBC-250-683 series
#Grup produk P112565109
Spesifikasi
| Capacitor Capacitance (F) | (Nominal value) 68000p |
|---|---|
| DC Resistance (Max.) | 3mΩ |
| Insulation Resistance (ohm) | 100 (DC500V min normal temperature and normal humidity) |
| Leakage Current | (Input 125 / 250V 60Hz) 2.5mA / 5.0mA max |
| Mass (kg) | Up to 13 |
| Operating Temperature (°C) | -40 to +85 |
| Outer dimensions, Width W x Height H x Depth D (mm) | 190 × 110 × 580 (excluding protrusions) |
| Rated Current (A) | 250 |
| Rated Voltage (V) | Three-phase three-wire system 500 (maximum use: 528) |
| Safety Standard | UL1283, CSA C22.2 No.8(C-UL), DIN EN60939 VDE0565 Teil 3-1, ENEC |
| Series | TBC |
| Storage Temperature / Humidity Range | -40 ~ + 85 °C, 20 ~ 95% RH (no condensation) |
| Vibration (m/s²) | 19.6 (10-55Hz (2G) cycle 3 minutes 1 hour each in X, Y, Z directions) |
