Can be linked with an external sensor. The load can be controlled by an external signal (a contact) such as a time switch or EE sensor. It can be opened and closed up to a high capacity of 30A.
Since it is a method that converts AC input to DC and holds it, it is quieter than electromagnetic contactors.
* Reverse connection is possible.
Panasonic Remote control breaker CS type (normally excited type) JIS agreement series for board
#Grup produk P112554468
Spesifikasi
| Connectable Stranded Wire (mm²) | (Main circuit) 14, (Operating circuit) 2 |
|---|---|
| Current Consumption (mA) | (Only during operation) 25 |
| Frame (AF) | 30 |
| Mass (kg) | 0.45 |
| Number of Poles/Elements | 2P2E |
| Operating Circuit Voltage (V) | AC200 |
| Operating Voltage Range (V) | (Operating circuit) 85% to 110% of rating |
| Overcurrent Tripper Type | Thermal / electromagnetic |
| Rated Breaking Capacity (kA) | 5(AC100/200V)/2.5(AC240V) |
| Rated Voltage (V) | AC100/200,AC240 |
| Terminal Shape | (Main circuit) Full-up terminal, (Operating circuit) Up terminal |
| Terminal screw | (Main circuit) M5, (Operating circuit) M3.5 |
| Tightening Torque (N m) | (Main circuit) 2.0 to 2.5, (Operating circuit) 0.5 to 0.7 |
