No need to specify time specifications when ordering
-△ With switching indicator
AC-free power supply compatible Short body 62.5 mm below the neck (screw tightening terminal type)
Compatible with .IP65 environmental resistance Panel cover can be replaced
Compatible with UL, CSA, CE marking and Lloyd
Panasonic PM4H-SD Star Delta Timer
#Grup produk P112553344
Spesifikasi
| Contact Configuration | (Timed contact) Input side: 1a, △ side: 1a |
|---|---|
| Mass (g) | About 110 |
| Operating Time | 2/10/20/100 seconds (4 range switching)-△ Switching time 0.04, 0.1, 0.3, 0.5, 0.7 seconds |
| Operating Voltage (V) | AC24 |
| Operation Mode | On- △ switching |
| Protection Class | IP65 (dustproof / jetproof type) |
| Standard | UL/C-UL ,CE ,Lloyd |
| Terminal | Screw terminal |
| Type | Main action: On-delay (-△ switch) |
