Panasonic PLC FP7RTD input unit
#Grup produk P112552725
Spesifikasi
| Ambient Humidity to Use | 10 to 95% RH (at 25 ° C, no condensation), Storage: 10 to 95% RH (at 25 ° C, no condensation) |
|---|---|
| Conversion speed | 25ms / ch + 25ms Add drift correction measurement time to the number of measurement channels |
| Current Consumption | 65 mA or less |
| Input range | (Resolution): RTD (resolution: 0.1 ° C) / Pt100 (1): -100.0 to 200.0 ° C Pt100 (2): -200.0 to 650.0 ° C JPt100 (1): -100.0 to 200.0 ° C JPt100 (2): -200.0 to 650.0 °C Pt1000: -100.0 to 100.0 °C |
| Insulation Resistance | 100MΩ or more (at 500V DC) |
| Mass (g) | About 145 |
| Number of Channels | 8 |
| Overall accuracy | ± 0.1% FS or less (at 25 ° C) ± 0.3% FS or less (at 0 to + 55 ° C) |
| Shock Resistance | 147m / s2 or more 3 times each in X, Y, Z directions (IEC61131-2) |
| Type of Insulation | Between input terminal and internal circuit: Photocoupler, isolated DC / DC converter, Between channels: Photomoss relay |
| Vibration Resistance | 5 to 8.4Hz, single amplitude 3.5mm, 1 sweep / minute (IEC61131-2), 8.4 to 150Hz, constant acceleration 9.8m / s2 10 sweeps (1 octave / min) (IEC6111-2) |
| Withstand Voltage | 500V AC for 1 minute |
