Panasonic PLC FP7 thermocouple multi-analog input unit
#Grup produk P112552707
Spesifikasi
| Ambient Humidity to Use | 10 to 95% RH (at 25 ° C, no condensation), Storage: 10 to 95% RH (at 25 ° C, no condensation) |
|---|---|
| Conversion speed | 5ms / ch + 5ms (Note) 25ms / ch + 25ms Add drift correction measurement time to the number of measurement channels (Note): AC noise elimination is disabled. |
| Current Consumption | 80 mA or less |
| Insulation Resistance | 100MΩ or more (at 500V DC) |
| Mass (g) | About 145 |
| Number of Channels | 8 |
| Overall accuracy | ± 0.1% FS or less (at 25 ° C) ± 0.3% FS or less (at 0 to + 55 ° C) |
| Shock Resistance | 147m / s2 or more 3 times each in X, Y, Z directions (IEC61131-2) |
| Type of Insulation | Between input terminal and internal circuit: Photocoupler, isolated DC / DC converter, Between channels: Photomoss relay |
| Vibration Resistance | 5 to 8.4Hz, single amplitude 3.5mm, 1 sweep / minute (IEC61131-2), 8.4 to 150Hz, constant acceleration 9.8m / s2 10 sweeps (1 octave / min) (IEC6111-2) |
| Withstand Voltage | 500V AC for 1 minute |
