Panasonic PLC FP7 Serial Communication Unit
#Grup produk P112552664
Spesifikasi
| Current Consumption | Approximately 50mA (when cassette is not installed) |
|---|---|
| Mass of Main Unit (g) | About 110 |
| Operating Ambient Humidity (%RH) | 10 to 95 (at 25°C, non-condensing), Storage: 10 to 95 (at 25°C, non-condensing) |
| ROHS Directive (Corresponding to 10 Substances) | Correspondence |
| Shock Resistance | 147m / s2 or more 3 times each in X, Y, Z directions (IEC61131-2) |
| Vibration Resistance | 5 to 8.4Hz, single amplitude 3.5mm, 1 sweep / minute (IEC61131-2), 8.4 to 150Hz, constant acceleration 9.8m / s2 10 sweeps (1 octave / min) (IEC6111-2) |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Feature
Specification●Number of units installed on CPU unit: Maximum 8 units ●CSA approved product (Certified): (File No.) E96300 (C-UL), (Standard No.) CAN/CSA-C22.2 No.61010-2-201 ●EMC Directive Applicable Standard: EN61131-2●UL Registered Product (Listed): (File No.) E96300, (Standard No.) UL 61010-2-201 ●Low Voltage Directive Applicable Standard: Not applicable ●Usage Atmosphere: Corrosive No gas. There should be no heavy dust. ●Product CE marking: ○Note) Cables and additional memory are not subject to applicable standards when used alone, so CE marking is not displayed on the product. When set with the PLC main unit, it complies with applicable directives. ●Noise resistance: 1000V [PP] Pulse width 50ns, 1μs (based on noise simulator method) ●Number of communication cassettes installed: Maximum 2 cassettes
