Panasonic PLC FP7 expansion cassette (communication cassette)
#Grup produk P112552309
Spesifikasi
| Communication Protocol | Half-duplex method |
|---|---|
| Current Consumption (mA) | 90 or less |
| Interface | RS-422/RS-485 2ch |
| Mass of Main Unit (g) | Approx. 25 (including terminal block) |
| Noise resistance | 1,000V[PP] pulse width 50ns, 1μs (by noise simulator method) |
| Number of Connections | Up to 99 units during general-purpose communication, up to 99 units during computer link, up to 16 units during inter-PLC link, up to 99 units during MODBUS-RTU |
| Operating Ambient Humidity (%RH) | 10 to 95 (at 25°C, no condensation), Storage: 10 to 95 (at 25°C, no condensation) |
| Operation Environment | No corrosive gas. There should be no excessive dust. |
| ROHS Directive (Corresponding to 10 Substances) | Correspondence |
| Shock Resistance | 147m / s2 or more 3 times each in X, Y, Z directions (IEC61131-2) |
| Synchronization Type | Asynchronous method |
| Transmission Method | Stop bit: 1bit/2bit, Parity: No/Yes (odd/even), Data length: 7bit/8bit, Start code: With/without STX, End code: CR/CR+LF/No/ETX |
| Transmission Speed | 300, 600, 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200, 230400 bit/s |
| Transmission distance | Maximum 1,200 m in RS-485 mode, Maximum 400 m in RS-422 mode |
| Vibration Resistance | 5 to 8.4Hz, single amplitude 3.5mm, 1 sweep / minute (IEC61131-2), 8.4 to 150Hz, constant acceleration 9.8m / s2 10 sweeps (1 octave / min) (IEC6111-2) |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Feature
SpecificationData sending order: Send from bit 0 on a character-by-character basis
