Panasonic PLC FP7 Communication Cassette
#Grup produk P112552202
Spesifikasi
| Atmosphere | No corrosive gas. There should be no excessive dust. |
|---|---|
| Communication Protocol | Half-duplex method |
| Current Consumption (mA) | 35 or less (Note) This is the increase in CPU current consumption. |
| Interface | RS-232C 1ch + RS-485 1ch |
| Mass of Main Unit (g) | Approx. 25 (including terminal block) |
| Noise resistance | 1000V[PP] Pulse width 50ns, 1μs (by noise simulator method) |
| Operating Ambient Humidity (%RH) | 10 to 95 (at 25°C, no condensation), Storage: 10 to 95 (at 25°C, no condensation) |
| ROHS Directive (Corresponding to 10 Substances) | Correspondence |
| Shock Resistance (m/s²) | 147 or more 3 times each in X, Y, and Z directions (IEC61131-2) |
| Synchronization Type | Asynchronous method |
| Transmission speed (bps) | 300, 600, 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200, 230400 |
| Transmission standard | Stop bit: 1bit/2bit, Parity: No/Yes (odd/even), Data length: 7bit/8bit, Start code: With STX/No STX, End code: CR/CR+LF/No/ETX, Data transmission order: Send from bit 0 in character units |
| Vibration Resistance | 5 to 8.4Hz, single amplitude 3.5mm, 1 sweep / minute (IEC61131-2), 8.4 to 150Hz, constant acceleration 9.8m / s2 10 sweeps (1 octave / min) (IEC6111-2) |
