Supports high-density mounting: width (5 mm) x length (20 mm) x height (12.5 mm)
IEC61010 Reinforced insulation compliant insulation distance (between contact and coil) Space: 5.29 mm or more, creepage: 5.35 mm or more Withstand voltage: 3,000 V, Surge withstand voltage: 6,000 V
Low power consumption: 110mW
Explosion-proof standard compliant (ANSI / ISA 12.12.01)
Output applications for various controllers such as industrial equipment / OA equipment, measuring equipment, test equipment, programmable controllers and temperature controllers
Panasonic PA-N relay
#Grup produk P112550444
Spesifikasi
| Contact Configuration | 1a |
|---|---|
| Contact Rated Control Capacity (Resistive Load) | AC250V 5A/DC30V 5A |
| Dimensions (mm) | 20x5x12.5 |
| Mass (g) | About 3 |
| Maximum Allowable Contact Current (A) | 5(AC)/5(DC) |
| Maximum Allowable Contact Voltage (V) | AC250/DC110(0.4A) |
| Protection Class | Plastic seal |
| Standard | UL/C-UL,TUV |
| Terminal Shape | Printed circuit board terminal |
