Panasonic FP7 function cassette (thermocouple input)
#Grup produk P112545503
Spesifikasi
| Ambient Humidity to Use | 10 to 95% RH (at 25 ° C, no condensation), Storage: 10 to 95% RH (at 25 ° C, no condensation) |
|---|---|
| Current Consumption (mA) | 45 or less |
| Input Impedance (kΩ) | 344 |
| Input range | Thermocouple K: -50.0 to 500.0°C, Thermocouple J: -50.0 to 500.0°C |
| Mass of Main Unit (g) | Approx. 25 (including terminal block) |
| Noise resistance | 1,000V[PP] pulse width 50ns, 1μs (by noise simulator method) |
| Number of Input Points | 2ch (isolated between channels) |
| Overall accuracy | ±0.5% FS or less + cold junction error: 1.5°C (0 to 55°C) |
| ROHS Directive (Corresponding to 10 Substances) | Correspondence |
| Resolution (°C) | 0.2 (displayed as 0.1 with software averaging) |
| Sampling Cycle | 100ms/2ch |
| Shock Resistance | 147m / s2 or more 3 times each in X, Y, Z directions (IEC61131-2) |
| Type of Connection | Connector type terminal block |
| Type of Insulation | Between thermocouple input terminal and internal digital circuit: transformer insulation, isolation IC insulation, between thermocouple input terminals: transformer insulation, isolation IC |
| Vibration Resistance | 5 to 8.4Hz, single amplitude 3.5mm, 1 sweep / minute (IEC61131-2), 8.4 to 150Hz, constant acceleration 9.8m / s2 10 sweeps (1 octave / min) (IEC6111-2) |
