Panasonic FP7 expansion cassette (communication cassette)
#Grup produk P112545488
Spesifikasi
| Atmosphere | No corrosive gas. There should be no excessive dust. |
|---|---|
| Communication Protocol | Half-duplex method |
| Current Consumption (mA) | 60 or less * Increase in CPU current consumption. |
| Interface | RS-422/RS-485 1ch |
| Mass of Main Unit (g) | Approx. 25 (including terminal block) |
| Noise resistance | 1000V[PP] pulse width 50ns, 1μs (by noise simulator method) |
| Operating Ambient Humidity (%RH) | 10 to 95 (at 25°C, no condensation), Storage: 10 to 95 (at 25°C, no condensation) |
| ROHS Directive (Corresponding to 10 Substances) | Correspondence |
| Shock Resistance (m/s²) | 147 or more 3 times each in X, Y, and Z directions (IEC61131-2) |
| Synchronization Type | Asynchronous method |
| Transmission distance (m) | RS-485 mode: maximum 1200m, RS-422 mode: maximum 400m *When C-NET adapters are mixed, the maximum number of connected units is 32, and the transmission speed is limited to 19.2 kbit/s or less. |
| Transmission speed (bps) | 300, 600, 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200, 230400 |
| Transmission standard | Stop bit: 1bit/2bit, Parity: No/Yes (odd/even), Data length: 7bit/8bit, Start code: With STX/No STX, End code: CR/CR+LF/No/ETX, Data transmission order: Send from bit 0 in character units |
| Vibration Resistance (Hz) | 5 to 8.4 single amplitude 3.5 mm 1 sweep/1 minute (IEC61131-2), 8.4 to 150 constant acceleration 9.8 m/s2 10 sweeps (1 octave/min) (IEC6111-2) |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
communication cassette
