Panasonic FP7 CPU Unit
#Grup produk P112545460
Spesifikasi
| Ambient Humidity to Use | 10 to 95% RH (at 25 ° C, no condensation), Storage: 10 to 95% RH (at 25 ° C, no condensation) |
|---|---|
| Communication Protocol | Half-duplex method |
| Conditions to Use | Operating atmosphere: No corrosive gases. No excessive dust. |
| Connector | General-purpose communication, computer link, MODBUS-RTU |
| Current Consumption | 200mA or less |
| Format Type | [Transmission] Stop bit: 1 bit/2 bit, Parity: None/Yes (Odd/Even), Data length: 7 bit/8 bit, Start code: Yes/No STX, End code: CR/CR+LF/None/ETX |
| Interface | RS-232C 3-wire 1CH *Terminals SD, RD, and SG are isolated from the internal circuit. |
| Mass of Main Unit (g) | Approximately 220 (including terminal block and end unit) |
| Noise resistance | 1,000V[PP] pulse width 50ns, 1μs (by noise simulator method) |
| ROHS Directive (Corresponding to 10 Substances) | Correspondence |
| Rated Voltage Range (V) | 20.4 to 28.8DC |
| Synchronization Type | Asynchronous method |
| Transmission Speed | 300, 600, 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200, 230400 bit/s |
| Transmission distance | 15m |
| Vibration/Shock Resistance | 5 to 8.4Hz Single amplitude 3.5mm 1 sweep/1 minute (IEC61131-2), 8.4 to 150Hz Constant acceleration 9.8m/s2 10 sweeps (1 octave/min) (IEC6111-2)/147m/s2 or more 3 times each in XYZ directions (IEC 61131-2) |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
*When replacing AFP7CPS31, the old expansion cassette cannot be installed on the new CPU unit and serial communication unit. Also, the new expansion cassette cannot be installed on the old CPU unit and serial communication unit. However, the programs are compatible.
Feature
SpecificationData sending order: Send from bit 0 on a character-by-character basis
