*This breaker is for systems where reverse power flow occurs from the generator side, such as solar power generation systems. (Cannot be used for reverse connection of general commercial power circuits.)
*This breaker cannot be used with residential distribution board Compact 21.
*When using a radio device such as a transceiver, please use it at least 1m away. The AA neutral wire open phase protection may malfunction (breaker trip).
*DIN rail mounting is not possible.
Panasonic Earth leakage breaker with AA neutral wire open phase protection for solar power generation systems
#Grup produk P112543781
Spesifikasi
| Dimensions, H x W x D (mm) | 96 (126 including terminal cover) x 75 x 60 (75.6 including handle) |
|---|---|
| Frame | 75AF |
| Lead Wire Length (mm) | Overvoltage detection: 0.5mm² xL200 |
| Mass (kg) | 0.5 |
| Number of Poles/Elements | 3P3E |
| Operating Time (s) | (at the time of overvoltage) within 0.5, (at the time of earth leakage) within 0.1 |
| Quantity | One-piece |
| Rated Sensitivity Current (mA) | 30 |
| Type | Main breaker only |
| Type of Display | Electric leakage/overvoltage: Mechanical button |
| Voltage Rating (V) | Overvoltage: 130±5 |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Description
Feature
SpecificationWith terminal cover, compatible with lightning surges and harmonics (inverters, etc.)
