Circuit breaker equipped with an earth leakage monitoring function.
In the unlikely event of an electric leakage, the display will notify you without interrupting the circuit.
* Reverse connection is not possible.
* Use the dedicated bar crimping terminal for the stranded wire 3.5 mm 2 , 5.5 mm 2 , 8 mm 2.
Panasonic Can touch breaker with leakage indicator
#Grup produk P112539344
Spesifikasi
| Frame (AF) | 50 |
|---|---|
| Mass (kg) | 0.16 |
| Number of Poles/Elements | 2P2E |
| Operating Time | (Display) within 0.1 seconds |
| Rated Breaking Capacity (kA) | 5(AC100/200V)/2.5(AC200V) |
| Rated Sensitivity Current (mA) | 30 |
| Rated Voltage (V) | AC100/200,AC200 |
| Suitable Terminal | (Crimp terminal) 2-5, 5.5-5, 8-5S (Quick connection terminal) Φ1.6, Φ2.0, Φ2.6 |
| Terminal Shape | (Power side) Crimp terminal, (Load side) Quick connection terminal |
| Type of Resetting | (Leakage display) Manual reset (push button) |
