IDEC RL Power Relay RL2N
#Grup produk P112506814
Sebelum PPN:
Rp4.499.900 - Rp4.699.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Allowable Current (A) | 25 (contact) |
|---|---|
| Contact | 2-pole |
| Contact Configuration | 2a |
| Contact Material | Ag alloy |
| Contact Rated Control Capacity (Resistive Load) | AC250V 25A |
| Electrical Durability | (Rated load) 100,000 times or more (opening/closing frequency 1200 times/hour) |
| Insulation Resistance (MΩ) | over 100 |
| Maximum Allowable Contact Current (A) | 25 |
| Maximum Allowable Contact Voltage (V) | AC277 |
| Mechanical Durability | (No load) 1 million times or more (opening/closing frequency 10,800 times/hour) |
| Number Of Poles (P) | 2 |
| Operating Ambient Humidity (%RH) | 5 to 85 (but not frozen) |
| Recommended Tightening Torque (N m) | 1 to 1.4 (contact terminal), 0.7 to 0.9 (coil terminal) |
| Return Time (ms) | 30 or less |
| Shock Resistance (m/s²) | Durability: 1000, Malfunction: 100 |
| Storage Temperature (°C) | -25 to 85 (but no freezing) |
| Terminal Shape | Screw terminal |
| Vibration Resistance | Durability: Frequency 10 to 55Hz, half amplitude 0.75mm/Malfunction: Frequency 10 to 55Hz, half amplitude 0.75mm |
| Withstand Voltage (V/minute) | Between contact circuit and coil: AC4000, between contact circuits: AC2000, between contacts of the same polarity: AC2000 |
