IDEC RF2 Type 2-pole forced guide Type relay
#Grup produk P112506577
Spesifikasi
| Coil Rated Voltage (V) | DC24 |
|---|---|
| Contact Configuration | 2c |
| Contact Material | AgNi+Au-Clad |
| Diode | With reverse polarity diode |
| Insulation Resistance (MΩ) | 1000 or more (DC500V mega) |
| Maximum Allowable Contact Current (A) | 6 |
| Maximum Allowable Contact Voltage (V) | AC250/DC125 |
| Mechanical Durability | Over 10 million times (opening and closing frequency 18,000 times/hour) |
| Number of Poles | 2 |
| Operating Ambient Humidity (%RH) | 5 to 85 (no condensation) |
| Operation Indicator | With operation display LED |
| Pollution Degree (Environment to Use) | 2 |
| Power Consumption (W) | About 0.7 |
| Protection Class | RT II |
| Rated Insulation Voltage (V) | 250 |
| Rated Load | NO contact: AC240V/6A, DC24V/6A, NC contact: AC240V/3A, DC24V/3A |
| Response Time (ms) | 20 or less |
| Return Time | 25ms or less |
| Specification | ●Breakdown type: Micro breaker ●Minimum applicable load: DC1V . 1mA |
| Terminal Shape | Plug-in terminal |
| Vibration Resistance (Destruction) | 10-55Hz, single amplitude 0.75mm |
| Vibration Resistance (Malfunction) | NO contact: 10 to 55Hz, half amplitude 0.75mm, NC contact: 10 to 55Hz, half amplitude 0.2mm |
| Withstand Voltage | 6000V (impulse) |
| Withstand Voltage (V/minute) | Between contact circuit and operating coil: AC5000, Between contacts of different polarities: AC4000, Between contacts of the same polarity: AC1500 |
