IDEC HG2G-V Type programmable display (high performance Type)
#Grup produk P112501217
Spesifikasi
| Allowable Voltage Range (V) | DC20.4~28.8 |
|---|---|
| Atmosphere | No corrosive gas |
| Display Size (mm) | 5.7 inch, TFT color LCD, 65536 colors |
| Inrush Current (A) | 30 or less |
| Isolation Voltage | AC1000V/10mA for 1 minute (between power supply terminal and functional ground terminal) |
| Noise resistance | Fast transient/burst test, power supply section: ±2kV, communication line: ±1kV (IEC/EN61131-2) |
| Operating Ambient Temperature (°C) | -20 to 60 (but no freezing) |
| Operation | analog touch switch |
| Outer Dimensions (mm) | 167.2(W)x134.7(H)x54.4(D) |
| Overload | 10-90 (however, no condensation) |
| Power Consumption (W) | 18 or less, 8 or less when USB2, EXT is not used, 4 or less when backlight is off |
| Protection Class | IP66F/IP67F (IEC 60529) (Front part when mounted on panel) TYPE 4X/TYPE 13 |
| Rated Voltage (V) | DC24 |
| Shock (m/s²) | 147 11ms (5 times each in X, Y, and Z directions) |
| Specification | ● Pollution degree: 2 ● Communication/memory interface: COM1, COM2, LAN, USB 1, USB 2, SD, EXT |
| Storage Temperature (°C) | -20 to 70 (However, do not freeze) |
| Type of Sign | Panel mount method (panel thickness: 1.6-5.0mm) |
| Vibration | 5 to 8.4Hz: Single amplitude 3.5mm, 8.4 to 150Hz: Acceleration 9.8m/s² (10 times each in X, Y, and Z directions (100 minutes)) |
