IDEC HG1P Type teaching pendant
#Grup produk P112501156
Spesifikasi
| Allowable Voltage Range (V) | DC20.4~28.8 |
|---|---|
| Display Size (mm) | 4.3 inch, TFT color LCD, 65536 colors |
| Inrush Current (A) | 20 or less |
| Isolation Voltage | AC500V . 10mA for 1 minute |
| Operating Ambient Temperature (°C) | 0 to 45 (but not freezing) |
| Operating Humidity (%RH) | 10-90 (however, no condensation) |
| Operation | Analog touch type and function switch |
| Outer Dimensions (mm) | 191(W)x168.9(H)x56(D) |
| Power Consumption (W) | 3 or less (when USB2 is not used: 2 or less) |
| Protection Class | IP54 (excluding cable connector) (IEC 60529) |
| Rated Voltage (V) | DC24 |
| Shock (m/s²) | 147 11ms (5 times each in X, Y, and Z directions) |
| Storage Temperature (°C) | -10 to 60 (no icing) |
| Vibration | 5 to 8.4Hz: half amplitude 3.5mm, 8.4 to 150Hz: constant acceleration 9.8m/s² , 1 octave 10 minutes (10 times each in X, Y, Z directions (100 minutes)) |
| cycle of insertion/removal | [Connector] HG1P type optional cable: 100 times, USB 1: 5000 times, USB 2: 1500 times |
