Mitsubishi Electric Remote I / O unit with IE field network security function
#Grup produk P112484099
Spesifikasi
| Dimensions, H x W x D (mm) | 100x23x111.5 |
|---|---|
| Inrush Current (A) | Maximum: 1.0/10 ms or less |
| Installation Location | Inside the control panel |
| Insulation Resistance (MΩ) | Between all DC external terminals and earth: DC500V, 10 or more with insulation resistance tester |
| Leakage Current (mA) | (OFF) 0.5 or less |
| Load current (mA) | Maximum: 500/1 point, 4000/1 common (when mounted on the front), for other than front mounting, see the derating diagram |
| Number of Outputs | 8 points (single wiring), 4 points (double wiring) |
| Output Format | Source + Source Type |
| Power Supply | Voltage: DC24V (ripple rate within 5%) (allowable voltage range DC20.4 to 28.8V), current: 20mA |
| Protection Class | IP2X |
| Protective Function | Output overload protection function |
| Rated Load Voltage (V) | DC24 (ripple rate within 5%) (allowable voltage range DC20.4 to 28.8) |
| Shock Resistance (m/s²) | Compliant with JIS B 3502 and IEC 61131-2 (147, action time 11 ms, sine half-wave pulse, 3 times each in XYZ/3 directions) |
| Type of Connection | (External wiring) Output section, external power supply section: 40-point 2-piece spring clamp terminal block |
| Type of Insulation | (Output) Photocoupler insulation |
| Voltage drop (V) | (Maximum when ON) DC1.0 or less |
