Mitsubishi Electric Q173D/Q172D motion controller + manual pulse generator input module
#Grup produk P112483771
Spesifikasi
| Current Consumption (A) | (DC5V)0.38 |
|---|---|
| Input Method | Tracking enable input: Shared sink/source (photocoupler isolation) |
| Mass (kg) | 0.15 |
| Number of Connections | Manual pulse generator/incremental synchronization, encoder input: 3 units/1 unit |
| Number of Input Points | 3 (Tracking Enable Input) |
| Occupied In/Out Points | 32 points (I / O allocation: intelligent function unit, 32 points) |
| Operating Voltage Range (V) | Tracking enable input: DC10.2 to 26.4 (ripple rate within 5%) |
| Outer Dimensions (mm) | 98.0(H)x27.4(W)x90.0(D) |
| Rated Input Current (A) | 0.002/0.004 |
| Rated Input Voltage (V) | DC12/DC24 |
| Response Time | Tracking enable input: 0.4ms/0.6ms/1ms (OFF→ON/ON→OFF) *Selectable by parameter, default 0.4ms |
| Specification | ON voltage/current: Tracking enable input: DC10V or more/2.0mA or more OFF voltage/current: Tracking enable input: DC1.8V or less/0.18mA or less |
