Mitsubishi Electric power amplifier
#Grup produk P112483230
Spesifikasi
| Ambient Humidity to Use | 35 to 85% RH (no condensation) |
|---|---|
| Atmosphere | There should be no corrosive gases, flammable gases, conductive dust, etc., and there should be no excessive dust. There should be no rain or water droplets. |
| Function | Main: Constant current/constant voltage control, torque nonlinearity correction function, stop timer, stop gain, stop bias |
| Ground | Class D ground |
| Insulation Resistance | 5MΩ or more with a DC500V insulation resistance tester (between all terminals together and the case) |
| Mass (kg) | About 2.5 |
| Mounting | Floor and wall mounting |
| Noise Immunity | Power supply: Noise voltage 1000Vp-p, noise width 1μs, frequency 30 to 100Hz, noise simulator |
| Output Signal | [Analog] Power amplifier output: DC 24 V 4 A or less, Auxiliary output: DC 10 V 2 A or less for 30 seconds or less, Load resistance: 4.8 Ω or less |
| Power Supply | Input: AC 100 to 240V (-15 to +10%) 50/60Hz Power consumption: 400VA Power fuse: 250V 8A built-in Inrush current: 50A 300ms [Output] Volume power supply: DC 8V, volume resistance: 500 to 2kΩ, reel sensor power supply: DC 12V, 15mA or less |
| ROHS Directive (Corresponding to 10 Substances) | Correspondence |
| Shock Resistance | 98m/s2 3 times each in 3 axis directions |
| Vibration Resistance | 10~55Hz 0.5mm (maximum 19.6m/s2) 2 hours each in 3 axis directions |
| Withstand Voltage (V) | AC1500 for 1 minute (between all terminals together and case) |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Feature
The LE-50PAU power amplifier is used to control the excitation current of powder clutches and brakes, and can also be used as a clutch amplifier for open-loop tension controllers or feedback tension controllers.Ulasan Produk
