Mitsubishi Electric Inverter FR-E700 Series
#Grup produk P112479316
Spesifikasi
| AC Voltage Tolerance (V) | 325 to 528(50/60Hz) |
|---|---|
| Ambient Humidity (% RH) | 90 or less (no condensation) |
| Applicable Motor Capacity (kW) | 0.75 |
| Cooling Method | Self-cooling |
| DC braking | Operating frequency (0 to 120Hz), operating time (0 to 10s), operating voltage (0 to 30%) variable |
| Dimension D (mm) | 141.5 |
| Frequency (Hz) | 50/60 |
| Frequency Characteristic | Base frequency 0 to 400Hz can be set arbitrarily, constant torque / reduced torque pattern can be selected |
| Frequency Tolerance | ±5% |
| Mass (kg) | 1.4 |
| Outer dimensions, Width W x Height H x Depth D (mm) | 140x150x141.5 |
| Output Frequency (Hz) | 0.2 to 400 |
| Output overload current rating | 150% 60s, 200% 3s (reverse time characteristic) |
| Output voltage (V) | 3-phase 380-480 |
| Power Supply | 3-phase 400V |
| Power Supply Capacity (kVA) | 2.5 |
| Power Supply Voltage (V) | 3 phase 400 |
| Protection Class | Closed type (IP20) |
| Rated Output Capacity (kVA) | 2 |
| Rated Output Current, Standard (A) | 2.6(2.2) |
| Rated input AC voltage (V) | (Power supply) 3-phase 380-480 (50Hz / 60Hz) |
| Series | FR-E740 |
| Storage Temperature (°C) | -20 to 65 |
| Type of control | Soft-PWM control / high carrier frequency PWM control (V / F control, general-purpose magnetic flux vector control, advanced magnetic flux vector control, optimum excitation control can be selected) |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Feature
Short-time maximum torque improved from 150% at the conventional drive frequency of 1 Hz to 0.5 Hz/200% (3.7 kW or less, 0.5 Hz/150% at 3.7 kW or more) Achieves even more tenacious operation Pursue ease of use Lightly at your fingertips Equipped with a rotatable dial-type operation unit "M dial" Equipped with a "simple setting mode" that selects whether to input the start command and frequency command from the outside or the operation panel Equipped with a USB connector as a standard interfaceUse
Used as a member mainly in the manufacturing industry such as transportation and food machineryUlasan Produk
