Mitsubishi Electric FX3S Series Basic Unit
#Grup produk P112477637
Sebelum PPN:
Rp4.399.900 - Rp5.399.900
Ketersediaan:
Periksa Metode Pembayaran dan Estimasi pengiriman
Spesifikasi
| Clock Function | Built-in +1980-2079 (with leap year correction), 2 digits / 4 digits, monthly difference ± 45 seconds / 25 ° C |
|---|---|
| Command | Sequence instruction: 29, step ladder instruction: 2, application instruction: 116 types |
| Communication port | (Built-in) RS-422, USB + Mini-B + 1ch each |
| Connection Shape | (Input/Output) M3 screw-type terminal block |
| Ground | Class D grounding (ground resistance: 100 Ω or less) <Common grounding with high-voltage systems is not possible> |
| In / Out control method | Batch processing method (when executing END instruction), input / output refresh instruction, pulse catch function |
| Input Format | DC24V sink / source |
| Installation Location | Inside the control panel |
| Insulation Resistance | Between each terminal and earth terminal: DC500V, 5MΩ or more using an insulation resistance tester |
| Noise resistance | Noise voltage 1000Vp-p, noise width 1μs, rise time 1ns, period 30 to 100Hz, noise simulator |
| Operating Temperature (°C) | 0 to 55 |
| Operation Environment | There is no corrosive or flammable gas, and there is not much conductive dust. |
| Output Format | Transistor (sink) |
| Output specifications | 0.5A / 1 point (0.8A / 4 points), DC5 ~ 30V |
| Program Memory Capacity | 4000 steps (16000+ steps including comments and file registers) |
| Rated Voltage (V) | DC24 |
| Series | FX3S |
| Shock Resistance | 147m/s², duration 11ms, half-sine pulse, 3 times each in X, Y, and Z directions |
| Storage Temperature (°C) | -25 to 75 |
| Type of control | [Calculation] Stored program Iterative calculation method, with interrupt function |
