Mitsubishi Electric FW-S series transformer unit
#Grup produk P112477530
Spesifikasi
| Ambient Temperature (°C) | 0-40 (recommended 20-30 |
|---|---|
| Frequency | (AC input) 50/60Hz ±5%, (AC output) UPS operation: 50/60Hz (synchronized with the output frequency of the connected UPS), UPS bypass: input frequency (dependent on the input frequency) |
| Input Capacity | 5.0kVA |
| Installation Type | Tower Type |
| Mass (kg) | About 55 |
| Number of Phases | (AC input/AC output) Single-phase two-wire system |
| Outer Dimensions, Width W x Depth D x Height H (mm) | 250x484x507 |
| Output Capacity | 5.0kVA/4.0kW |
| Paint Color | Gray |
| ROHS Directive (Corresponding to 10 Substances) | Correspondence |
| Relative Humidity | 25 to 85% RH or less (no condensation) |
| Terminal Block | (AC input/AC output) M4 terminal block |
| Type | (Product) Terminal block and outlet specifications |
| Voltage (V) | (AC input) AC185 to 260, (AC output) UPS operation: 200-240 ±5% (depending on the output setting of the connected UPS), UPS bypass: 200-240 (within ±10% of input voltage) |
Pilih jenis produk yang diinginkan
| Nomor SKU | Model Number | Masa Persiapan Barang | Harga | Jumlah |
|---|---|---|---|---|
| Loading... | ||||
Apakah produk dengan spesifikasi yang Anda inginkan belum tersedia? Hubungi tim Layanan Pelanggan kami di sini
Informasi Produk
Warning
Please refer to the New Product News (No.U013) for compatible UPS units. Please use the 100V output from the UPS main unit. Make sure the total output does not exceed the rated capacity of the UPS.Feature
Wide variety It can be combined with the FW-S series 5.0kVA UPS unit. It can also be combined with an environmentally resistant UPS, allowing you to create combinations that meet your needs. Freedom of installation: The transformer unit is installed separately from the UPS main unit. It also contributes to making the panel more compact. (It consists of two units: the UPS main unit and the transformer unit. When installed side by side, a space about twice the width of the FW-V20 is required.) Output voltage can be selected. Output voltage can be set to 200V or 100V. Customers can flexibly use either 200V for power or 100V for control power supply depending on their application.Ulasan Produk
