Mitsubishi Electric Electromagnetic Contactor High Sensitivity Contactor SD-Q Series
#Grup produk P112476319
Spesifikasi
| Applicable Motor Capacity (kW) | Single-phase motor (AC-3 class): 0.2 (100-110V)/0.4 (200-220V), Three-phase squirrel-cage motor (AC-3 class): 2.5 (200-240V)/4 (380-440V)/4 (500-550V) |
|---|---|
| Applicable Rail Width (mm) | 35 |
| Auxiliary Contact | 2a |
| Coil Rated Voltage (V) | DC24 |
| Current Capacity (A) | Breaking: Rated operating voltage 220V: 120, Rated operating voltage 440V: 90, Closed circuit: Rated operating voltage 220V: 120, Rated operating voltage 440V: 90 |
| Electrical Durability | AC3 class: 1 million times (the auxiliary contact is rated 500,000 times) |
| Frame | Q12 |
| Length (mm) | 51 |
| Mass (kg) | 0.21 |
| Mechanical Durability | 10 million times |
| Open thermal Current (A) | 20 |
| Operating Frequency (operation/hour) | 1800 |
| Operating Time (ms) | Coil ON → Main contact ON: 50 or less, Coil OFF → Main contact OFF: 20 or less |
| Operating Voltage | 85% or less of rated voltage |
| ROHS Directive (Corresponding to 10 Substances) | Correspondence |
| Series | SD-Q |
| Standard | JIS JEM, IEC, DIN VDE, BS EN, UL, CSA, CE mark, TUV, GB |
| Thickness (mm) | 66.5 |
| Type | Open type |
| Type of Operation | Irreversible |
| Type of Sign | IEC 35mm rail, screw |
| Width (mm) | 54 |
